What this guide decides.
This page decidesWhich gate and access-control inputs must appear in the drawing, quotation and approval record.
This page does not decideMachinery safety, powered-gate compliance, emergency egress, lock rating or access-control design approval.
Name every opening.
Give each pedestrian, vehicle, maintenance and emergency opening an ID. Record clear width and height, leaf arrangement, swing or sliding direction, normal state, duty cycle, adjacent road or aisle and required manual override.
Treat the closed leaf as a system.
Review frame stiffness, mesh infill, hinges or rollers, stop and hold-open arrangements, latch and lock protection, gaps at meeting stiles, hinge sides and thresholds, and the transition to fixed fence posts.
Allocate control responsibility.
State who supplies readers, locks, sensors, interlocks, cabling, conduits, local panels, power, network connections, programming and commissioning. A fence supplier should not silently inherit electronic-system design.
Review abnormal conditions.
Include power loss, fire or emergency release, manual operation, maintenance isolation, obstruction, drainage, snow or debris and recovery after impact. The responsible parties must resolve conflicts between security, life safety and operations.
Plan access for installation and lifecycle service.
Confirm how frames and leaves reach the opening, where lifting and setup can occur, how coatings are protected, and which parts need future removal space. Schedule keys, credentials, spare hardware, specialist tools, operating instructions, settings and as-built records. Handover should name the owner of routine checks, powered equipment service, access-control faults and any condition that requires the opening to be placed under temporary control.
Choose the gate around movement and control.
The opening type is only one decision. Traffic, available space, operating frequency and abnormal states determine the full interface schedule.
Coordinate each opening before the fence schedule is frozen.
Use one opening ID across architectural, civil, gate, electrical and security documents.
- 01
Fix the operational brief
State users, vehicles, clear dimensions, operating frequency, normal position, security state and conditions requiring manual or emergency operation.
- 02
Select and draw the movement
Confirm swing, slide or other operation against gradients, roads, kerbs, drainage, adjacent fence, buildings, overhead constraints and maintenance access.
- 03
Schedule the physical security
Identify frame, infill, hinges or rollers, meeting stiles, stops, lock protection, guards and every perimeter gap or transition.
- 04
Write the control narrative
Describe credential, command, release, monitoring, obstruction, fail state, alarm, bypass, manual override and restoration without assuming another package will supply them.
- 05
Test the complete opening
Verify geometry, movement, closing, locking, signals, abnormal conditions and records with the responsible parties present.
Project-input schedule.
Carry these fields into the enquiry, drawing review and approval record. Mark unknowns as open items instead of guessing.
Gate questions that prevent late redesign.
- What is the clear opening and which movement envelope must remain unobstructed?
- What happens during power, network, fire-alarm or access-control failure?
- Which party supplies and commissions locks, sensors, conduits, cabling and operators?
- How are threshold, hinge-side, meeting-stile and fence-transition gaps reviewed?
- Where can the leaf, vehicle or pedestrian queue safely during operation?
- Which acceptance tests and records are required before handover?
