Fabricated steel grating panel system
Heavy-Duty Steel Grating Walkway Mesh
A fabricated steel grating family for walkways, platforms, stairs and trench covers, configured by bearing-bar direction, span, supports, loading, edge treatment, finish and project drawings.
Provide the panel schedule, clear spans, support layout, loads, deflection criteria, surface requirement, cut-outs, fixing method and applicable design standard.
- Form
- Welded or pressure-locked steel grating
- Duty
- Project-defined span and loading
- Fabrication
- Panels, bands, cut-outs and treads
- Final basis
- Approved schedule and engineering criteria
Where this product family fits.
- Walkway, platform, stair and trench applications with defined loads and supports.
- Fabricated panel schedules that identify bearing-bar direction, span, cut-outs and edges.
- Projects with responsible structural design and an approved fixing and finish basis.
What must not be assumed.
- Load capacity, span, slip resistance or code compliance inferred from a photograph.
- Interchangeability between grating types without bearing-bar and support review.
- Application imagery treated as structural calculation, test or completed-project evidence.
Define these decisions before comparing configurations.
The page collects the variables that change suitability, scope and price. It does not replace the approved drawing, quotation or responsible engineering review.
Supports
Provide clear spans, support widths and bearing-bar direction.
Grating strength is directional.Schedule
List every panel size, quantity, banding and cut-out.
Controls fabrication.Surface
Define serration, drainage and slip-resistance requirements.
Environment and maintenance matter.Fixing
Confirm clips, welding, removable panels and edge restraints.
Keeps installation scope explicit.Finish
State material, galvanizing or coating and exposure.
Defines corrosion protection.Configurable specification sheet.
Values shown here describe the supply variables. Exact dimensions, finishes and components are confirmed for the project.
Send the missing inputs →| Field | Current supply basis | What to confirm |
|---|---|---|
| Bearing bars | Project-selected depth, thickness and spacing | Provide load and span criteria. |
| Cross bars | Welded or locked configuration by specification | Confirm type and spacing. |
| Panels | Fabricated to approved schedule | Provide dimensions and tolerances. |
| Edges | Banding, nosing and cut-outs by drawing | Identify every opening. |
| Surface | Plain or project-defined serrated option | State slip and drainage basis. |
| Finish | Raw, galvanized or coated by scope | Confirm exposure. |
| Final basis | Approved engineering criteria and panel schedule | No load rating is implied by images. |
From requirement to approved supply.
The sequence keeps product selection, engineering responsibility and commercial scope aligned.
- 01
Define the zone
Provide the protected, screened or controlled area, its purpose and a dimensioned plan.
- 02
Coordinate openings
Schedule personnel, material and maintenance access with clear widths and hardware expectations.
- 03
Review interfaces
Confirm floor, columns, walls, services, supports, locks and any controls requirements.
- 04
Approve supply
Release only after drawings, finish, scope, quantities, packing and responsibility boundaries are approved.
